ACSS Maglock Double 600lb Internal Use Only - Anodised Aluminium
The ACSS MLSH02T is a double door electromagnetic lock designed for internal access control applications. This fail safe maglock unlocks on power loss and is intended for paired door leaves in controlled indoor environments.
The lock body is finished in anodised aluminium and operates on 12 V DC or 24 V DC, making it suitable for a wide range of access control systems.
Key Features
- Double door electromagnetic lock for internal use.
- Fail safe operation unlocks on power loss.
- Holding force up to 600 lb (272 kg) per door.
- Dual voltage operation at 12 V DC or 24 V DC.
- Built-in relay timer adjustable from 0 to 90 seconds.
- Bi-colour LED status indication.
- Anodised aluminium housing.
- Built-in voltage spike suppressor.
Specifications
- Item Code: MLSH02T
- Brand: ACSS
- Lock Type: Double door electromagnetic lock
- Locking Mode: Fail safe
- Monitoring: Non-monitored
- Working Voltage: 12 V DC or 24 V DC
- Current Draw: 1 A at 12 V DC, 500 mA at 24 V DC
- Holding Force: 600 lb (272 kg) per door
- Timer: Built-in relay timer 0 to 90 seconds
- Ingress Use: Internal use only
- Finish: Anodised aluminium
- Fire Rated: No
Dimensions
Download PDF Resources
|
MLSH0102 – Product Datasheet |
Suitable Uses
- Internal commercial access control systems.
- Office, retail, and controlled industrial environments.
- Double leaf doors requiring electromagnetic locking.
Frequently Asked Questions
Is this maglock suitable for external doors?
No. This model is designed for internal use only.
What happens if power is lost?
As a fail safe lock, the doors will unlock when power is removed.
Are mounting brackets included?
No. L and Z mounting brackets are available separately.
Additional Information
- Fail safe electromagnetic locks are commonly specified where emergency egress compliance is required.
- Double door maglocks are used where paired leaves must unlock simultaneously.
- Correct door alignment is critical to achieving full holding force.
