Lockwood Heavy Duty Mortice Hub Spring 8mm Hub 127mm

Lockwood Heavy Duty Mortice Hub Spring 8mm Hub 127mm

Lockwood

Was: $638.63
Now: $470.10
(No reviews yet) Write a Review
SKU:
STK 5772NSF8SS
UPC:
9340116015392
Adding to cart… The item has been added

Lockwood 5772NSF8SS — MkII Universal Primary Lock, Heavy Duty Hub Spring, 8 mm Hub, 127 mm Backset Satin Stainless

The Lockwood 5772NSF8SS is a Selector® 5772 MkII universal primary mortice lock featuring a heavy-duty hub spring and 8 mm hub design. With a 127 mm extended backset and finished in Satin Stainless Steel (SS), this lock is engineered for high-traffic commercial and institutional environments. It delivers secure deadlatching, in-door function configurability, and is compatible with Lockwood 570 oval cylinders and a wide range of commercial furniture.

Delivery truck icon Estimated Warehouse Dispatch: 11 Days
Caution icon Non-Returnable Item: This product cannot be returned once purchased

Key features icon Key Features

  • Universal mortice lock body — Selector® MkII platform.
  • 127 mm backset for extended clearance door preps.
  • 8 mm hub design with heavy-duty hub spring for increased durability in high-use environments.
  • Satin Stainless Steel faceplate provides strength and architectural appeal.
  • In-door configuration: red/green selector under the faceplate for function adjustments.
  • Compatible with Lockwood 570 oval cylinders and master key systems.
  • Retrofits into existing Synergy® case sizes for easy replacement or upgrade.

Fire rating icon Fire Rated

  • Tested up to 4 hours on fire door assemblies (AS 1905.1:2005).

Specifications icon Specifications

  • Item Code: 5772NSF8SS
  • Function: Universal primary mortice lock body (MkII, 8 mm hub, heavy-duty spring).
  • Backset: 127 mm.
  • Hub: 8 mm, heavy-duty hub spring.
  • Finish: Satin Stainless Steel (SS).
  • Door Thickness: 32–50 mm standard; extension kits available up to 200 mm.
  • Bolt: 15 mm stainless steel latch with auxiliary deadlatch.
  • Case: Zinc alloy with stainless steel chassis.
  • Handing: Reversible without case disassembly.
  • Compliance: AS4145.2 (Durability D8, Security S7); AS1905.1 (Fire Doors).

Contents icon What's In The Box

  • 1 × Lockwood 5772NSF8SS mortice lock body (127 mm backset, 8 mm hub, heavy-duty hub spring)
  • 1 × Satin Stainless Steel faceplate
  • 1 × Satin Stainless Steel strike plate
  • Fixing screws
  • Installation instructions

Suitable uses icon Suitable Uses

  • Commercial and institutional doors requiring an extended 127 mm backset.
  • High-traffic applications needing an 8 mm hub with heavy-duty spring for longevity.
  • Fire-rated escape and entry doors requiring certified mortice hardware.
  • Retrofit upgrades from Synergy® mortice locks to Selector® MkII platform.

Product code list icon Selector® 5772 MkII Escape Locks — Item Code Family (127 mm Backset)

Item Code Function Description
5772 Escape Lock (Primary) Base mortice escape lock, 127 mm backset. Inside handle always free; outside handle rigid.
5772V Anti-vandal Escape Outside handle operable when unlocked; outside key locks/unlocks & retracts latch; inside always free.
5772VT Anti-vandal + Turn Cylinder outside, turn inside; inside always free; outside key locks/unlocks & retracts latch.
5772X Key Entry Escape Outside opened by key at all times (handle rigid); inside handle always free.
5772XT Key Entry + Turn Outside opened by key; inside by turn/handle. Inside always free; outside key locks outside handle.
5772-V Internal Cylinder Inside handle always free; inside key locks/unlocks outside handle & retracts latch after unlocking.
5772-T Internal Turn Inside handle always free; internal turn locks/unlocks outside handle.
5772VV Anti-vandal, Double Cylinder Outside key locks/unlocks outside handle; inside cylinder also operates bolt; inside always free.
5772XV Key Entry, Double Cylinder Outside key entry at all times; inside always free; inside key locks/unlocks outside handle & retracts latch.
5772-TA Anti-lockout + Turn Prevents accidental lockout; inside turn; outside handle operable when unlocked; inside always free.
5772VTA Anti-lockout Anti-vandal + Turn Cylinder outside, turn inside; combines anti-vandal control with anti-lockout reset.
5772V-H Holdback Anti-vandal Latch can be held in; outside key locks/unlocks; inside always free. Not fire-door rated.
5772XVH Holdback Key Entry, Double Cylinder Double cylinder; holdback function; inside always free. Not fire-door rated.
5772VTH Holdback Anti-vandal + Turn Cylinder outside, turn inside; holdback enabled. Not fire-door rated.

Accessories icon Selector® 5772 MkII — Accessories & Spares (Std. Backset Series)

Item Code Description Notes
3772-FINKITCP / PB / PC Alternative Finish Kits Strike + faceplate + screws. Use to match CP/PB/PC finishes on 3770/4772/5772 platforms.
3772-RK32XX / 3772-RK46XX Rebate Kits (4hr Fire Rated) For 13 mm rebates; lip 32/46 mm. Finishes: SS, CP, PB. “XX” = finish.
3772-AFKITSS / CP / PC Aluminium Door Fixing Kit Converts timber-fix lock to aluminium-fix; 156×25 mm radius faceplate.
3772-STK25 / 32 / 43 / 47 / 60 Short/Extended Lipped Strikes Lip 25–60 mm. Finishes: SS, CP, PB (60 mm only SS).
3772-STKBOX Strike Box (Pk=10) Box cavity behind strike for clean latch engagement.
3772-2100SS ES2100 Electric Strike Faceplate For timber/standard fixing with ES2100 monitored strikes.
3772AF-2100SS ES2100 Faceplate — Aluminium Fix For aluminium-fix installations using ES2100 strike.
3772-SECKIT Security Faceplate Screw Kit 2 × TR20 tamper-resistant screws to replace standard faceplate screws.
SP3570-5018 / -5228 / -5238 / -5258 Extended Spindles Door thickness coverage ≈ 32–200 mm (variant dependent).
SP3700/X7CAM X7 Cam (Latching) Retracts latch; interfaces with locking bar.
SP3700/VCAM V Cam (Locking) Locks/unlocks bar; retracts latch after unlocking.
3770M2-ADAPTOR MkII Latching/Turn Adaptor MkII only (not backward compatible with MkI).
3772-DXKITSC DX Mechanical Digital Kit Codepad + plate + spindle + latching adaptor (furniture ordered separately).
3772-DXKOKITSC DX Digital with Key Override Kit As DXKIT plus lower cylinder provision for key override.
3777-KIT Dual Entry Conversion Kit Lower cylinder plate + spindle cam + screws (two cylinders outside).

Warranty icon Warranty

  • Lockwood 25 Year Mechanical Warranty covers mechanical components and workmanship under normal use and correct installation.
  • Electronic and electrical components are covered for 3 years (PADDE & electric mortice locks 5 years, batteries excluded).
  • Keys are covered for 12 months.
  • Finish warranty varies by finish type and exposure — e.g. Everbrass 25 years; Stainless/Chrome/Anodised 10 years; PVD/VIVID 10 years; Symmetry range 5 years; decorative finishes such as bronze, antique and powdercoat 2 years (natural brass ageing excluded).
  • Warranty excludes misuse, improper installation, modification, or failure to maintain as specified.
