Lockwood 4772SS — MkII Universal Primary Lock 89 mm Backset Satin Stainless

The Lockwood 4772SS is a Selector® 4772 MkII universal primary mortice lock with an 89 mm backset and Satin Stainless Steel (SS) finish. Built for durability, this lock is ideal for heavy-duty commercial and institutional applications such as offices, schools, hospitals, and industrial buildings. It features in-door configuration, secure deadlatching, and compatibility with Lockwood cylinders and furniture ranges.

Delivery truck icon Estimated Warehouse Dispatch: 11 Days

Key features icon Key Features

  • Universal mortice lock body for Selector® MkII series.
  • 89 mm backset — extended clearance for specialised door prep.
  • Satin Stainless Steel faceplate for durability and clean aesthetics.
  • Secure deadlatching bolt with auxiliary latch.
  • In-door configuration: red/green selector under faceplate for simple adjustment.
  • Compatible with Lockwood 570 oval cylinders and restricted/master key systems.
  • Reversible handing without disassembly.

Fire rating icon Fire Rated

  • Tested up to 4 hours on compliant fire door assemblies (AS 1905.1:2005).

Specifications icon Specifications

  • Item Code: 4772SS
  • Function: Universal primary mortice lock body (MkII platform).
  • Backset: 89 mm.
  • Finish: Satin Stainless Steel (SS).
  • Door Thickness: 32–50 mm standard; extension kits available up to 200 mm.
  • Bolt: 15 mm stainless steel latch with auxiliary deadlatch.
  • Case: Zinc alloy with stainless steel chassis.
  • Handing: Reversible without disassembly.
  • Standards: AS4145.2 (Durability D8, Security S7); AS1905.1 (Fire Doors).

Contents icon What's In The Box

  • 1 × Lockwood 4772SS mortice lock body (89 mm backset)
  • 1 × Satin Stainless Steel faceplate
  • 1 × Satin Stainless Steel strike plate
  • Fixing screws
  • Installation instructions

Suitable uses icon Suitable Uses

  • Heavy-duty commercial and institutional doors requiring extended backset locks.
  • High-traffic environments such as schools, hospitals, offices, and hotels.
  • Fire-rated escape doors requiring certified mortice lock hardware.
  • Retrofits where 89 mm backset Selector® MkII lock is specified.

Product code list icon Selector® 4772 MkII Escape Locks — Item Code Family (89 mm Backset)

Item Code Function Description
4772 Escape Lock (Primary) Base mortice escape lock, 89 mm backset. Inside handle always free; outside handle rigid.
4772V Anti-vandal Escape Lock Outside opened by key when unlocked; inside handle always free.
4772VT Anti-vandal + Turn Cylinder outside, turn inside; inside handle always free.
4772X Key Entry Escape Outside opened by key at all times; inside handle always free.
4772XT Key Entry + Turn Outside opened by key; inside by turn/handle. Inside handle always free.
4772-V Internal Cylinder Inside handle always free; inside key locks/unlocks outside handle.
4772-T Internal Turn Inside handle always free; turn locks/unlocks outside handle.
4772VV Anti-vandal, Double Cylinder Outside key locks/unlocks outside handle; inside cylinder also operates bolt.
4772XV Key Entry, Double Cylinder Outside key entry at all times; inside handle always free; inside key controls outside handle.
4772-TA Anti-lockout + Turn Prevents accidental lockout; inside turn; inside handle always free.
4772VTA Anti-lockout Anti-vandal + Turn Cylinder outside, turn inside; combines anti-vandal & anti-lockout.
4772V-H Holdback Anti-vandal Latch can be held in; outside key locks/unlocks; inside always free. Not fire-door rated.
4772XVH Holdback Key Entry, Double Cylinder Double cylinder; holdback function; inside always free. Not fire-door rated.
4772VTH Holdback Anti-vandal + Turn Cylinder outside, turn inside; holdback enabled. Not fire-door rated.

Accessories icon Selector® 4772 MkII — Accessories & Spares

Item Code Description Notes
3772-FINKITCP / PB / PC Alternative Finish Kits Strike + faceplate + screws. Use to match CP/PB/PC finishes.
3772-RK32XX / 3772-RK46XX Rebate Kits (Fire Rated) For 13 mm rebates; lip 32/46 mm. Finishes: SS, CP, PB.
3772-AFKITSS / CP / PC Aluminium Door Fixing Kit Converts timber-fix to aluminium-fix; 156×25 mm radius faceplate.
3772-STK25 / 32 / 43 / 47 / 60 Short/Extended Lipped Strikes Lip 25–60 mm. Finishes: SS, CP, PB (60 mm only SS).
3782-FSTK32SS / 64SS Fabricator Strikes (Short Backset Series) Stainless “D” strikes (32/64 mm) — for 3780 series frames where applicable.
3782-RFSTKCP / PB / SC Retrofit Strike Kits Replacement strike kits for existing installs; finish matched.
3772-STKBOX Strike Box (Pk=10) Box cavity behind strike for cleaner latch engagement.
3772-2100SS ES2100 Electric Strike Faceplate Suits timber/standard fixing; DPS capable strikes.
3772AF-2100SS ES2100 Faceplate — Aluminium Fix For aluminium-fix installations with ES2100 strike.
3772-SECKIT Security Faceplate Screw Kit 2× TR20 tamper-resistant screws to replace standard faceplate screws.
SP3570-5018 / -5228 / -5238 / -5258 Extended Spindles Door thickness coverage ~32–200 mm (variant dependent).
SP3700/X7CAM X7 Cam (Latching) Retracts latch and interfaces with locking bar.
SP3700/VCAM V Cam (Locking) Locks/unlocks bar; retracts latch after unlocking.
3770M2-ADAPTOR MkII Latching/Turn Adaptor MkII only (not backward compatible with MkI).
3772-DXKITSC DX Mechanical Digital Kit Codepad + plate + spindle + latching adaptor (furniture ordered separately).
3772-DXKOKITSC DX Digital with Key Override Kit As DXKIT plus lower cylinder provision for key override.
3777-KIT Dual Entry Conversion Kit Lower cylinder plate + spindle cam + screws (two cylinders outside).

Warranty icon Warranty

  • Lockwood 25 Year Mechanical Warranty covers mechanical components and workmanship under normal use and correct installation.
  • Electronic and electrical components are covered for 3 years (PADDE & electric mortice locks 5 years, batteries excluded).
  • Keys are covered for 12 months.
  • Finish warranty varies by finish type and exposure — e.g. Everbrass 25 years; Stainless/Chrome/Anodised 10 years; PVD/VIVID 10 years; Symmetry range 5 years; decorative finishes such as bronze, antique and powdercoat 2 years (natural brass ageing excluded).
  • Warranty excludes misuse, improper installation, modification, or failure to maintain as specified.
