Lockwood Mortice Heavy Duty Hub Spring 60 mm Backset

Lockwood Mortice Heavy Duty Hub Spring 60 mm Backset

Lockwood

Was: $365.45
Now: $269.01
(No reviews yet) Write a Review
SKU:
STK 3772NSFSS
UPC:
9340116090207
Adding to cart… The item has been added

Lockwood 3772NSFSS — Selector® 3772 MkII Universal Primary Lock HD Hub Spring 60 mm Backset Satin Stainless

The Lockwood 3772NSFSS is the Selector® 3772 MkII Universal Primary Lock fitted with a heavy-duty hub spring for enhanced durability in high-use doors. With a 60 mm backset and Satin Stainless Steel finish, this mortice escape lock provides dependable single-action egress and multiple function configuration options, making it suitable for the most demanding commercial and institutional applications.

Delivery truck icon Estimated Warehouse Dispatch: 2 Days

Key features icon Key Features

  • Universal primary mortice lock body for the Selector® 3772 MkII platform.
  • Fitted with heavy-duty hub spring for increased strength and extended service life.
  • Escape lock design: inside handle always allows free egress.
  • 60 mm backset (standard). Extended backset versions (89 mm, 127 mm) available separately.
  • Reversible handing — suits left or right hand doors without disassembly.
  • Compatible with Lockwood 570 oval cylinders, restricted systems, and a wide range of escutcheons and turns.
  • Designed for high-traffic commercial, institutional, and public buildings.

Fire rating icon Fire Rated

  • Successfully fire tested up to 4 hours on fire door assemblies (AS 1905.1 compliant).

Specifications icon Specifications

  • Item Code: 3772NSFSS
  • Function: Universal primary mortice escape lock body (MkII)
  • Backset: 60 mm
  • Hub: Heavy-duty hub spring
  • Material: Zinc alloy case with stainless steel faceplate
  • Door Thickness: 32–50 mm (extension packs available for thicker doors)
  • Handing: Reversible
  • Finish: Satin Stainless Steel (SS)
  • Standards: AS4145.2 (Durability D8, Security S7, Corrosion C6)

Contents icon What's In The Box

  • 1 × Lockwood 3772 MkII Universal Primary Lock (HD hub spring, 60 mm backset)
  • 1 × Stainless steel faceplate
  • 1 × Strike plate
  • Fixing screws
  • Installation instructions

Suitable uses icon Suitable Uses

  • Commercial, institutional, and public buildings requiring robust escape locks.
  • High-traffic doors needing enhanced hub spring strength.
  • Fire-rated egress doors where compliance with AS1905.1 is mandatory.
  • Retrofit replacement for Synergy 3572SC primary locks with direct compatibility.

Product code list icon Selector® 3772 MkII Escape Locks — Item Code Family

Item Code Function Description
3772 / 4772 / 5772 Escape Lock (Primary) Base mortice escape lock, 60 / 89 / 127 mm backset. Inside handle always free, outside handle rigid.
3772V Anti-vandal Escape Lock Outside opened by key when unlocked; inside always free.
3772VT Anti-vandal Escape Lock + Turn Cylinder outside, turn inside; inside always free.
3772X Key Entry Escape Lock Outside opened by key at all times; inside handle always free.
3772XT Key Entry Escape Lock + Turn Outside opened by key; inside opened by turn or handle.
3772-V Escape Lock with Internal Cylinder Inside: handle always free; key inside locks/unlocks outside handle.
3772-T Escape Lock with Turn Inside: handle always free; turnknob locks/unlocks outside handle.
3772VV Anti-vandal Escape Lock with Internal Cylinder Double cylinder; outside key locks/unlocks handle; inside key also operates bolt.
3772XV Key Entry Escape Lock with Internal Cylinder Double cylinder; outside key entry at all times; inside always free.
3772-TA Anti-lockout Escape Lock + Turn Turn inside; outside handle operable when unlocked. Prevents accidental lockout.
3772VTA Anti-lockout, Anti-vandal Escape Lock + Turn Cylinder outside, turn inside; anti-vandal and anti-lockout functions combined.
3772V-H Holdback Anti-vandal Escape Lock Latch can be held in; outside key locks/unlocks; inside always free. Not fire door rated.
3772XVH Holdback Key Entry Escape Lock with Internal Cylinder Double cylinder; holdback function; inside always free. Not fire door rated.
3772VTH Holdback Anti-vandal Escape Lock + Turn Cylinder outside, turn inside; holdback enabled. Not fire door rated.

Accessories icon Selector® 3772 MkII Escape Locks — Accessories & Spares

Item Code Description Notes
3772-FINKITCP / PB / PC Alternative Finish Kits Includes strike, faceplate & screws. CP=Chrome Plate, PB=Polished Brass, PC=Powdercoat.
3772-RK32XX / 3772-RK46XX Fire Rated Rebate Kits Suits 13 mm rebates. Lip lengths 32 mm or 46 mm. Finishes: SS, CP, PB.
3772-AFKITSS / CP / PC Aluminium Door Fixing Kit Converts timber fix to aluminium door fixing. 156×25 mm faceplate. Finishes: Stainless, Chrome Plate, Powdercoat.
3772-STK25 / STK32 / STK43 / STK47 / STK60 Short / Extended Lipped Strikes Lip lengths 25–60 mm. Finishes: SS, CP, PB. (STK60 only in SS).
3772-2100SS / 3772AF-2100SS ES2100 Electric Strike Faceplates Suits Selector® 3770 Series. AF version for aluminium fixing. For monitored electric strikes.
3772-SECKIT Security Faceplate Screw Kit Includes 2 × tamper resistant TR20 torx drive screws.
SP3570-5018 / -5228 / -5238 / -5258 Extended Spindles For thicker doors (32–200 mm). Supplied individually or in packs.
SP3700/X7CAM X7 Cam Latching cam. Retracts latchbolt, locks/unlocks locking bar.
SP3700/VCAM V Cam Locks/unlocks locking bar, retracts latch bolt after unlocking.
3770M2-ADAPTOR Latching/Turn Adaptor Adaptor for MkII mortice locks. Not backwards compatible with MkI.
3772-DXKITSC DX Digital Conversion Kit Includes digital codepad, mounting plate, spindle, screws, and latching adaptor.
3772-DXKOKITSC DX Digital with Key Override Kit As above, with lower cylinder assembly for key override.
3777-KIT Dual Entry Conversion Kit Lower cylinder mounting plate, spindle cam & screws. Converts 3772 to dual entry (two cylinders outside).

Warranty icon Warranty

  • Lockwood 25 Year Mechanical Warranty covers mechanical components and workmanship under normal use and correct installation.
  • Electronic and electrical components are covered for 3 years (PADDE & electric mortice locks 5 years, batteries excluded).
  • Keys are covered for 12 months.
  • Finish warranty varies by finish type and exposure — e.g. Everbrass 25 years; Stainless/Chrome/Anodised 10 years; PVD/VIVID 10 years; Symmetry range 5 years; decorative finishes such as bronze, antique and powdercoat 2 years (natural brass ageing excluded).
  • Warranty excludes misuse, improper installation, modification, or failure to maintain as specified.
