Lockwood 1820 Sq. End Plate w Cyl. Hole & Led & 74 Lvr SC
1820 SQUARE END PLATE WITH CYLINDER HOLE & LED & 74 LEVER Satin Chrome
Estimated Warehouse Dispatch: 6 Days
***Non-Returnable Item***
Lockwood 1800 Series Square End Plate Brass Furniture
Style and versatility are combined in this range which comprises of architecturally designed plates which give you the flexibility to mix and match to suit the aesthetics of every application.
Lockwood Brass Plate furniture is made from the highest quality materials and is available in a comprehensive array of levers in a range of superb finishes that provide complete freedom of choice.The Lockwood Brass Door Furniture range is the culmination of decades of experience in the design and manufacture of high quality door furniture.
Over the years the Lockwood brass door range has evolved as the product of choice for leading architects in commercial, institutional and industrial applications.
Chunky, funky and functional, the Lockwood Lever Ving means business.
A strong design statement, ideal for numerous heavy duty applications.
The 1800 Series
Key Features
- a classic rectangular plate with bevelled edges suiting corporate, commercial and public spaces with high use requirements. Designed for use with Lockwood Synergy 3570 and Selector 3770 Series Mortice Locks.
- Features Lockwood lever Ving 74.
- External plate with concealed fixing (screws included).
- Oval turn with LED.
- Cylinder pitch 64mm.
- Fixing centres 148mm.
- Non-handed.
- Supplied in trade pack.
- Plate Dimensions.
- Height: 166mm.
- Width: 48mm.
- Depth: 12mm.
- Lever Dimensions.
- Length: 120mm.
- Projection: 65mm.
- Finger clearance: 48mm.
- When using plate configurations that feature turns a unique mechanism is employed that automatically adjusts the length of the tail bar to suit a particular door thickness.
- Handing.
- Symmetrical levers may be reversed by removing the stop screw.
- Fixing.
- Plates are designed to fit back to back. If outside plate is specified with concealed fixing, then the inside plate must be visible fixed.External plates are supplied with fixing screws to suit door thickness between 32mm and 45mm.
- Warranty: 25-year mechanical warranty.
