Lockwood 1370 Series 74 Lever On Round Rose Full Set SC
1370 SERIES 74 LEVER ON ROUND ROSE FULL SET Satin Chrome
Estimated Warehouse Dispatch: 6 Days
***Non-Returnable Item***
Lockwood 1370 Series Round Rose Brass Furniture
The Lockwood 1370 Series door furniture is manufactured from high quality solid brass material.
The comprehensive lever range matched with concealed screw fixings by way of threaded rose trims, provides a stylish look for the most elegant interiors.
Proudly made to the highest quality standards for strength, durability and corrosion resistance.
Lockwood Brass Furniture is made from the highest quality materials and is available in a comprehensive array of levers in a range of superb finishes that provide complete freedom of choice.
The Lockwood Brass Door Furniture range is the culmination of decades of experience in the design and manufacture of high quality door furniture.
Over the years the Lockwood Brass Door Furniture range has evolved as the product of choice for leading architects in commercial, institutional and industrial applications.
The 1370 Series rose furniture
Key Features
- a 62mm solid brass rose with diagonal screw fixings, concealed on the outside and visible on the inside. Chunky, funky and functional, the Lockwood Lever Ving means business. A strong design statement, ideal for numerous heavy duty applications.
- Application.
- Designed for use with Lockwood 5260 Latches, Synergy 3570 and Selector 3770 Series Mortice Locks.
- Features Lockwood Lever 74 Ving.
- Full set with interior and exterior roses.
- 2 x M4 x 65mm SS screws supplied (SP1220-119).
- Non-handed.
- Supplied in trade pack.
- Rose Dimensions.
- Dimensions: 62.5mm x 11.6mm.
- Fixing centres: 51mm.
- Lever Dimensions.
- Length: 120mm.
- Projection: 53mm.
- Finger clearance: 45mm.
- Materials.
- All Lockwood roses and levers contained in the series are of solid brass construction.
- Handing.
- Levers of symmetrical design may be reversed by removing stop screw.
- Fixing.
- Roses are designed to fit back to back. If outside rose is specified with concealed fixing, then the inside rose must be visible fixed. Roses numbered 1370, 1372, and 1374 are concealed fixed, roses numbered 1371, 1373 and 1375 are visible fixed.
- The 1370 Series rose furniture features a 62mm solid brass rose with diagonal screw fixings, concealed on the outside and visible on the inside.
- Door Thickness.
- 33mm minimum for 5260 Latches.
- 32mm minimum for Lockwood 3770 Selector and 3570 Synergy series mortice latches.
- 50 maximum door thickness.
- Warranty: 25-year mechanical warranty.
