Interlock 230 4BC NF Stainless Steel Non-Friction Stay – P1090NF
The Interlock 230 4BC NF is a non-friction 4-bar stainless steel hinge designed for projecting side hung (PSH) casement window sashes.
This model is specified where a window control mechanism provides the opening resistance and hinge friction is not required.
Manufactured from 304 grade austenitic (non-magnetic) stainless steel, the 4BC Series caters for residential and light commercial casement window applications.
This product is a hinge stay only. Window operators, restrictors and fixings are not included.
3 Days
Key Features
- Non-friction (NF) configuration.
- 4-bar stainless steel hinge construction.
- Manufactured from 304 grade austenitic stainless steel.
- Non-magnetic corrosion resistant material.
- No sliding channels.
- Fixed directly through bearing eyelet and formed screw/rivet holes.
- New Zealand made.
- Supplied as a pair.
Full Specifications
Dimensions
All dimensions shown are in millimetres. Letters correspond to the manufacturer’s A–N dimension table for the 430 4BC stainless steel casement hinge.
Frequently Asked Questions
When should I use the NF version?
Use the NF version when a window control mechanism provides opening resistance.
Is this suitable for top hung windows?
No. The 4BC Series is for projecting side hung windows.
What sash width can this support?
Maximum sash width is 800mm.
Additional Information
- Select hinge size based on sash width and weight.
- Recommended where window height is approximately twice window width.
- No fire rating stated in manufacturer documentation.
